Error Code Description EtherCAT Programming Guide
34-2 March, 2017
34
34.1 List of error code
When using the API of EtherCAT_Dll, the API function will return a value that shows the
execution result. Please refer to the following table for the description of those values. For
example, if the API function returns 0, it means the API is successfully executed. On the other
hand, a non-zero value is regarded as an error code. It means an error has occurred during
operation or hardware connection. Please troubleshoot the problem according to the description
below.
List of error code
Returned
value
(Decimal)
Name of the error code Description
0 ERR_ECAT_NO_ERROR No error
1 ERR_ECAT_HW_NO_INITIALIZE Hardware has not been initialized.
2 ERR_ECAT_HW_PWM_INITIAL Fail to initialize the hardware.
3 ERR_ECAT_HW_HAS_INITIALIZED Hardware is initialized repeatedly.
16 ERR_ECAT_EEPROM_READ Fail to read the EEPROM of the module.
17 ERR_ECAT_EEPROM_WRITE
Fail to write the data to the EEPROM of the
module.
18
ERR_ECAT_ENVIRONMENT_
RECORD_DISABLE
The Autoconfig file is not found.
19
ERR_ECAT_ENVIRONMENT_
RECORD_NO_MATCH
The hardware connection configuration saved
by Autoconfig file does not match the one for
Fieldbus.
20
ERR_ECAT_ENVIRONMENT_
RECORD_FILE_OPEN
Fail to open the Autoconfig file.
21
ERR_ECAT_ENVIRONMENT_
RECORD_NOT_CREATE
The Autoconfig file for saving the hardware
connection configuration has not been
created.
23 ERR_ECAT_DEVICE_OPEN
The setting for initializing EtherCAT Master is
in error.
24 ERR_ECAT_NO_DEVICE
The module data that is loaded during the
initial stage of EtherCAT Master initialization is
in error.
25 ERR_ECAT_NO_MASTER EtherCAT Master not found.
26 ERR_ECAT_NO_SLAVE EtherCAT Slave not found.
27 ERR_ECAT_UNKNOWN_SLAVE
There is an unknown module type on the
EtherCAT bus.
28 ERR_ECAT_IST_CREATE Fail to create IST.
29 ERR_ECAT_MASTER_CREATE Fail to create EtherCAT Master.
