User Manual for DEVO-12 Page 10 of 238
11 ELEV Trim 27 Throttle stick
12 RUDD Trim 28 AILE Trim
13 Power SW 29 ENT
14 EXT 30 R+
15 UP+ 31 L-
16 DN- 32
33
4.2 Rear definition
1. AUX 5
2. Regulation holes for throttle stick tension.
3. Charge socket (CHG): input DC at 5V, 500-1000 mA; Polarity:
.
4. AUX 4
