1
Receiver
DEVO-RX1201
10 Gear servo
2 Antenna 11 AUX 1
3 Battery 12 AUX 2
4 Power switch 13 AUX 3
5 Charge jack 14 AUX 4
6 Elevator servo 15 AUX 5
7 Aileron servo 16 AUX 6
8 Throttle servo 17 AUX 7
9 Rudder servo 18
4.4 Function keys in panel
There are 6 functional keys in the panel of DEVO-12. Below are the details:
1) EXT: Resetting key. Press EXT to exit the menu.
2) ENT: Confirmation key. Press ENT to get access to the system or the function
mode.
3) UP+: Function-selecting key. Move cursor up to the forward function item.
4) DN-: Function-selecting key. Move cursor down to the next function item.
5) R+: Move cursor rightwards to increase the setting value.
6) L-: Move cursor leftwards to decrease the setting value.
5.0 Control stick adjustment
The control stick adjustment includes parts: control stick length adjustment and
control stick tension adjustment.
5.1 Control stick length adjustment
1) Prolong the stick length: CCW rotate the stick head until the length you desire,
and then CCW tighten the stick sleeve.
2) Shorten the stick length: CW rotate the stick sleeve until the length you desire,
and then CW tighten the stick head.
