3.3 Sub trim
Sub Trim is used to make parallel movement of servos. It is recommended to adjust
the servo bell crank if the servo is far away from its neutral point. The excessive usage
of sub trim may damage the servo.
Setting method:
Touch the icon
to enter Function Menu and then click the icon to
enter the interface of Sub Trim.
Touch the navigation mark of the desired item to adjust the amount for rectifying the
servo’s neutral point. The default neutral point is set at 0.0%. The adjustment range of
each channel is shown as below:
English Your language English Your language
Channel name Adjustment range
Right elevator D62.5%-U62.5%
Right aileron 1 R62.5%-L62.5%
Throttle L62.5%-H62.5%
Rudder R62.5%-L62.5%
Left aileron 1 R62.5%- L62.5%
Flap D62.5%- U62.5%
Right aileron 2 R62.5%- L62.5%
Left aileron 2 R62.5%- L62.5%
AUX4 -62.5%- +62.5%
AUX5 -62.5%- +62.5%
