DA 62 AFM General
1.4 DIMENSIONS
NOTE
All dimensions shown below are approximate.
Overall Dimensions
Span : 14.57 m 47 ft 10 in
Length : 9.17 m 30 ft 1 in
Height : 2.82 m 9 ft 3 in
Wing
Airfoil : Wortmann FX 63-137/20 - W4
Wing Area : 17.10 m² 184.1 sq.ft.
Mean aerodynamic chord : 1.247 m 4 ft 1 in
Aspect ratio : 12.8
Dihedral : 5.2°
Leading edge sweep : 1°
Aileron
Area (total, left + right) : 0.65 m² 7 sq.ft.
Doc. No. 11.01.05-E Rev. 0 11-Jan-2019 Page 1 - 5
