Mass and Balance DA 62 AFM
6. Graphical method:
Diagram 6.4.2 - LOADING DIAGRAM is used to determine the moments. The masses
and moments for the individual items of loading are added. Then Diagram 6.4.5 -
PERMISSIBLE MOMENT RANGE is used to check whether the total moment
associated with the total mass is in the permissible range.
The result found with the graphical method is however inaccurate. In doubtful cases
the result must be verified using the exact method given above.
Page 6 - 8 Rev. 0 11-Jan-2019 Doc. No. 11.01.05-E
