Operating Limitations DA 62 AFM
2.6 WARNING, CAUTION AND ADVISORY ALERTS
2.6.1 WARNING, CAUTION AND ADVISORY ALERTS ON THE G1000
NOTE
The alerts described in the following are displayed on the
Garmin G1000. Section 7.10 includes a detailed description
of the alerts.
The following tables show the color and significance of the warning, caution and advisory
alerts lights on the G1000.
Color and Significance of the Warning Alerts on the G1000
Warning Alerts
(Red)
Meaning/Cause
WARNING One of the warnings listed below is being indicated.
L/R ENG TEMP
Left/Right engine coolant temperature is in the upper red
range (too high/> 100 °C [212 °F]).
L/R OIL TEMP
Left/Right engine oil temperature is in the upper red range
(too high/> 139 °C [282 °F]).
L/R OIL PRES
Left/Right engine oil pressure is in the lower red range
(too low/< 0.9 bar [13.05 psi]).
L/R FUEL TEMP Left/Right fuel temperature is in the upper red range (too
high/> 60 °C [140 °F])
L/R GBOX TEMP Left/Right engine gearbox temperature is in the upper red
range (too high/> 120 °C [248 °F]).
L/R FUEL PRESS Left/Right engine fuel pressure is low.
Page 2 - 14 Rev. 0 11-Jan-2019
DOT
approved
Doc. No. 11.01.05-E
