Operating Limitations DA 62 AFM
2.8 CENTER OF GRAVITY
Datum Plane
The datum plane (DP) is a plane which is normal to the airplane’s longitudinal axis and
in front of the airplane as seen from the direction of flight. The airplane’s longitudinal axis
is parallel with the floor of the nose baggage compartment. When the floor of the nose
baggage compartment is aligned horizontally, the datum plane is vertical. The datum plane
is located 2.196 meters (86.46 in) forward of the most forward point of the root rib on the
stub wing (refer to figure in Section 6.2).
Center of Gravity Limitations
The center of gravity (CG position) for flight conditions must be between the following
limits:
Most forward flight CG:
2.340 m (92.13 in) aft of datum plane at 1600 kg (3527 lb) to 1800 kg (3968 lb)
2.460 m (96.85 in) aft of datum plane at max. take-off mass (see Section 2.7)
linear variation in between
Most rearward flight CG:
2.460 m (96.85 in) aft of datum plane at 1600 kg (3527 lb)
2.510 m (98.82 in) aft of datum plane at 1900 kg (4189 lb) to 1999 kg (4407 lb)
2.530 m (99.61 in) aft of datum plane at MTOM
linear variation in between
Refer to Section 6.4.4 for a graphical illustration of the CG limitations.
WARNING
Exceeding the center of gravity limitations reduces the
controllability and stability of the airplane.
Page 2 - 20 Rev. 0 11-Jan-2019
DOT
approved
Doc. No. 11.01.05-E
