Airplane Description DA 62 AFM
Static Port Heating (if OÄM 62-037 is installed)
The static pressure ports, which provide measurement for the Pitot-static system, are
electrically heated and located on the RH and LH fuselage side walls. The heating is
activated in combination with the Pitot heating system (PITOT HEAT switch). The switch
is located on the instrument panel. On ground, the maximum temperature is limited by
means of an on-ground switch, to prevent overheating. The function of the system must
be checked on ground before take-off during walk-around.
External Power Socket
The DA 62 has an external 28 Volt DC power socket located on the lower surface of the
fuselage nose section. When external power is connected, the control relay is energized
and the external power comes online.
The socket itself has three pins:
• a large negative pin
• a large positive pin
• a small positive pin
A diode protects the system from reverse polarity.
28V Power Outlet Option (if OÄM 62-1002 is installed)
The DA 62 has a 28V power outlet at the lower right of the instrument panel. Only
equipment, that has been certified specifically for this outlet may be used. In case of any
malfunction of the equipment or any of the alternators, the equipment must be
disconnected or switched off.
For more information refer to the Airplane Maintenance Manual.
Page 7 - 68 Rev. 0 11-Jan-2019 Doc. No. 11.01.05-E
