2.5 ENGINE INSTRUMENT MARKINGS
Engine instrument markings and their color code significance are shown in the tables
below.
Indi-
cation
Red
arc/bar
=
lower
prohibited
range
Yellow
arc/bar
=
caution
range
Green
arc/bar
=
normal
operating
range
Yellow
arc/bar
=
caution
range
Red
arc/bar
=
upper
prohibited
range
RPM -- --
up to
2200 RPM
2200 to 2300
RPM
above
2300 RPM
Oil
pressure
below 0.9 bar 0.9 to 2.5 bar 2.5 to 6.0 bar 6.0 to 6.5 bar
above
6.5 bar
Oil
temp.
below -30°C -30° to 50°C 50° to 135°C
135° to
139°C
above 139°C
Coolant
temp.
below -30°C -30° to 60°C 60° to 95°C 95° to 100°C above 100°C
Gearbox
temp.
below -30°C -30° to 35°C 35° to 115°C
115° to
120°C
above 120°C
Load -- -- up to 95% 95 - 100% --
Fuel
temp.
below -30°C -- -30° to 55°C 55° to 60°C above 60°C
Ammeter -- -- up to 60A 60 to 70A above 70A
Volt-
meter
below 24.1V 24.1 to 25V 25 to 30V 30 to 32V above 32V
Fuel qty.
below
1 US gal
--
1 to 25
US gal
-- --
