DA 62 AFM Airplane Description
Alternate Means II for Fuel Quantity Indication for the Fuel Tank:
For an exact indication, the airplane must stand on horizontal ground with the wings level.
The fuel indicator II includes a protractor for an additional pitch angle measurement. The
fuel indicator II is placed on the LH nose baggage compartment floor. The lower edge
of the fuel indicator II must be supported by the nose baggage compartment for the entire
length. Read and record the pitch angle.
Standard Tanks:
Unfold the fuel indicator II and center it at the nose of wing. Read the fuel level on the
scale and refer to the tables provided in order to determine the exact fuel quantity.
Auxiliary Tanks (if installed):
Unfold the fuel indicator II and place it on the trailing edge of the center wing. Read the
fuel level on the scale and refer to the tables provided in order to determine the exact
fuel quantity.
Doc. No. 11.01.05-E Rev. 0 11-Jan-2019 Page 7 - 51
