DA 62 AFM Mass and Balance
6.4.1 MOMENT ARMS
The most important lever arms aft of the Datum Plane:
Item
Lever Arm
[m] [in]
Occupants on front seats 2.30 90.6
Occupants on rear seats, row I 3.25 128.0
Occupants on rear seats, row II (if OÄM 62-019 is
installed)
4.15 163.4
Fuel
in main tanks 2.63 103.5
in auxiliary tanks 3.20 126.0
De-Icing fluid tank in LH nose baggage compartment 0.90 35.4
Baggage in
compartments
LH Nose baggage compartment 0.47 18.5
RH Nose baggage compartment 0.05 2.0
Rear baggage compartment (Section A,
if OÄM 62-019 is NOT installed)
4.06 159.8
Rear baggage compartment
(Sections B, C, D, if OÄM 62-019 is
NOT installed)
4.18 164.4
Rear baggage compartment
(Section E, if OÄM 62-019 is installed)
4.41 173.6
Rear baggage compartment
(Section F, if OÄM 62-019 is installed)
4.18 164.4
Doc. No. 11.01.05-E Rev. 0 11-Jan-2019 Page 6 - 9
