DA 62 AFM Airplane Description
7.7 BAGGAGE COMPARTMENTS
7.7.1 NOSE BAGGAGE COMPARTMENTS
There are two nose baggage compartments, one LH and one RH. They are located in
the nose section of the airplane and are accessible through the LH and RH baggage doors
respectively.
7.7.2 REAR BAGGAGE COMPARTMENT
There is a rear baggage compartment aft of the passenger seats row 1. The rear baggage
compartment is accessible via the passenger door on the LH side of the airplane. The
compartment is divided into 4 zones, A, B, C and D, as described on limitation placard.
Zones A and B are boxes below floor level. The hatches of the boxes must be closed
during flight.
Zone C is the volume from the floor level up to the upper edge of the forward compartment
bulkhead. Forward shifting of items is prevented by the bulkhead.
Place heavy items in Zone C.
Zone D is the volume above Zone C up to the ceiling.
Baggage must be secured at all times by means of the approved baggage net. Only
baggage net attachment configuration in accordance with Figures 1 through 3 may be
used. Always use the most suitable baggage net configuration to secure the baggage
against shifting.
In case additional straps are used to secure the baggage from shifting, the maximum
pre-tension on a single D-Ring is 8 kg (17.6 lbs).
If OÄM 62-019 is carried out, the rear baggage compartment consists of Zones E and
F. Zone F is the volume from the folded backrest of passenger row II up to the ceiling.
Zone E is the baggage tray below floor level.
Doc. No. 11.01.05-E Rev. 0 11-Jan-2019 Page 7 - 21
