DA 62 AFM Airplane Description
7.15 MID CONTINENT MD302 STANDBY ATTITUDE MODULE
The Mid Continent MD302 Standby Attitude Module is a self-contained situational
awareness instrument that provides airplane attitude, altitude, airspeed and slip indication.
The Standby Attitude Module consists of two separate LCD displays. The upper display
serves as artificial horizon and the lower display as airspeed indicator and altimeter. The
user interface of the Standby Attitude Module allows for simple, intuitive operation using
a single push-and-turn control knob.
Refer to the Mid Continent MD302 Standby Attitude Module Pilot’s Guide, P/N 9017846
in the latest effective issue for more information.
The MD302 Standby Attitude Module is not connected to an external ARINC 429 source
(Garmin G1000), thus heading information and automatic BARO synchronization is not
available in the DA 62.
Doc. No. 11.01.05-E Rev. 0 11-Jan-2019 Page 7 - 93
