DA 62 AFM Mass and Balance
Airplane Serial No.: Registration: Date: Mass Lever Arm
Description Type Part No. Manufacturer S/N installed lb kg in m
ELECTRICAL POWER
Main battery RG24-15 Concorde
Emergency battery D60-2560-91-00 Diamond Aircraft
ECU backup battery LH (2 pcs.) LC-R127R2P Panasonic
ECU backup battery RH (2 pcs.) LC-R127R2P Panasonic
Additional Alternator ES-10024B-2 Kelly Aerospace
Alternator Pulley D64-2416-00-761 Diamond Aircraft
Gear Box Fan Assy D44-2416-20-00 Diamond Aircraft
Prop. Flange Pulley Support D44-2416-00-52_1 Diamond Aircraft
Additional Alternator V-belt ISO 4184 XPZL987 Diamond Aircraft
Additional Alternator Regulator VR2000_28-1 Electrosystems Inc.
OXYGEN SYSTEM
Oxygen cylinder (empty)
incl. pressure regulator
4110-122-3-11 Aerox 13.76 6.24 31.9 0.81
Oxygen cylinder 50 cuft (empty)
incl. pressure regulator
4110-136-02-5 Aerox 8.60 3.90 27.8 0.70
Single outlet manifold, Pax row I 4110-401-2-01 Aerox 0.22 0.10 111.0 2.82
Double outlet manifold, Pilot / copilot 4110-400-2 Aerox 0.42 0.19 103.9 2.64
Double outlet manifold, Pax Row I 4110-400-2 Aerox 0.42 0.19 111.0 2.82
Double outlet manifold, Pax Row II 4110-400-2 Aerox 0.42 0.19 153.5 3.90
Filling block 4110-405-2 Aerox 0.46 0.21 16.5 0.42
Pressure gauge 4110-486 Aerox 0.11 0.05 66.9 1.70
Push / pull control knob 4110-495 Aerox 0.27 0.12 66.1 1.68
