Interfaces Wide Area Networks (WANs)
AnywhereUSB® Plus User Guide
140
n
Separation of untrusted Internet traffic from trusted internal network traffic.
n
Secure connection to internal customer network without using a VPN.
n
Separate billing structures for public and private traffic.
n
Site-to-site networking, without the overhead of tunneling for each device.
In the following example configuration, all traffic on LAN1 is routed through the public APN to the
internet, and all traffic on LAN2 is routed through the private APN to the customer's data center:
To accomplish this, we will create separate WWAN interfaces that use the same modem but use
different APNs, and then use routing roles to forward traffic to the appropriate WWAN interface.
Note Dual-APN connections with the Telit LE910-NAv2 module when using a Verizon SIM are not
supported. Using an AT&T SIM with the Telit LE910-NAv2 module is supported. The Telit LE910-NAv2
module is used in the 1002-CM04 COREmodem.
ÉWebUI
1. Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.
2. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Increase the maximum number of interfaces allowed for the modem:
a. Click Network > Modems > Modem.
b. For Maximum number of interfaces, type 2.
4. Create the WWAN interfaces:
In this example, we will create two interfaces named WWAN_Public and WWAN_Private.
a. Click Network > Interfaces.
b. For Add Interface, type WWAN_Public and click g.
c. For Interface type, select Modem.
