Hardware AnywhereUSB 24 Plus: Front Panel
AnywhereUSB® Plus User Guide
792
Item Name Description
5
Fan2 LED The LED shows the status of Fan 2:
Solid green
The fan is running within normal range of use.
Solid red
The fan slows down or the Hub is overheating.
5
User LED LED used for the Find Me feature. When this feature is activated, the LED
blinks orange and then green.
5
PSU1 LED Solid blue
The Hub is powered on.
Solid red
The Hub is not powered or the supply has
failed.
5
PSU2 LED Solid blue
The Hub is powered on.
Solid red
The Hub is not powered or the supply has
failed.
5
Wi-Fi Service
LED
Reserved for future use.
5
WWAN1
Signal LED
WWAN2
Service LED
The WWAN1 Signal and WWAN2 Service LEDs how the status of the WWAN
connection while actions are being taken by the modem firmware. After all
actions are completed, the WWAN Signal LED shows modem strength and
the WWANService LED shows additional information.
See WWAN LED description table below for more information.
WWAN Service and WWANSignal LED descriptions
WWAN Signal LED WWANService LED Description
Slow flash red Slow flash red Updating modem firmware
Slow flash green Slow flash green Recovering modem firmware
Off Slow flash green Waiting for modem to appear
Off Off Modem not present.
