Interfaces Bridging

AnywhereUSB® Plus User Guide

207

Bridging

Bridging is a mechanism to create a single network consisting of multiple devices, such as Ethernet

devices and wireless access points.

By default, the AnywhereUSB Plus has the following preconfigured bridges:

You can modify configuration settings for the existing bridge, and you can create new bridges.

This section contains the following topics:

Edit the preconfigured ETH2 bridge 208

Configure a bridge 211
