Services Location information

AnywhereUSB® Plus User Guide

251

Location information

Your AnywhereUSB Plus device can be configured to use the following location sources:

User-defined static location.

Location messages forwarded to the device from other location-enabled devices.

You can also configure your AnywhereUSB Plus device to forward location messages, either from the

AnywhereUSB Plus device or from external sources, to a remote host. Additionally, the device can be

configured to use a geofence, to allow you to determine actions that will be taken based on the

physical location of the device.

This section contains the following topics:

Configure the location service 252

Configure the device to use a user-defined static location 253

Configure the device to accept location messages from external sources 255

Forward location information to a remote host 259

Configure geofencing 265

Show location information 277
