Monitoring intelliFlow

AnywhereUSB® Plus User Guide

442

setup

Default value: internal

Current value: internal

(config)>

b. Set the zone to be used by IntelliFlow:

(config)> monitoring intelliflow zone my_zone

5. Save the configuration and apply the change:

(config)> save

Configuration saved.

6. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
