Monitoring Configure NetFlow Probe

AnywhereUSB® Plus User Guide

451

d. (Optional) Set a label for the collector:

(config monitoring netflow collector 0)> label "This is a collector."

(config monitoring netflow collector 0)>

Repeat to add additional collectors.

10. Save the configuration and apply the change:

(config monitoring netflow collector 0)> save

Configuration saved.

11. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
