Central management Collect device health data and set the sample interval

AnywhereUSB® Plus User Guide

461

(config)> show monitoring devicehealth tuning

all

cellular

bytes

enable true

bytes

enable true

eth

bytes

enable true

bytes

enable true

serial

bytes

enable true

bytes

enable true

cellular

bytes

enable true

packets

enable true

...

(config)>

To disable a tuning parameter, set its value to false. For example, to turn off all reporting for

the serial port:

(config)> monitoring devicehealth tuning all serial rx bytes enabled

false

(config)> monitoring devicehealth tuning all serial tx bytes enabled

false

(config)>

7. Save the configuration and apply the change:

(config)> save

Configuration saved.

8. Type exit to exit the Admin CLI.

Depending on your device configuration, you may be presented with an Access selection

menu. Type quit to disconnect from the device.
