Virtual Private Networks (VPN) OpenVPN

AnywhereUSB® Plus User Guide

624

Certificates and keys:

The CA certificate (usually in a ca.crt file).

The Public key (for example, client.crt)

The Private key (for example, client.key).

Additional configuration items

The route metric for the OpenVPN client.

The login credentials for the OpenVPN client, if configured on the OpenVPN server.

Additional OpenVPN parameters.

See Configure SureLink active recovery for OpenVPN for information about OpenVPN active recovery.

ÉWebUI

1. Log into the AnywhereUSB Plus WebUI as a user with full Admin access rights.

2. On the menu, click System. Under Configuration, click Device Configuration.

The Configuration window is displayed.

3. Click VPN > OpenVPN > Clients.

4. For Add, type a name for the OpenVPN client and click g.

The new OpenVPN client configuration is displayed.
