Configure the AnywhereUSB Manager from the command line list full

AnywhereUSB® Plus User Guide

773

VENDOR: SanDisk

VENDOR ID: 0x0781

PRODUCT: Cruzer

PRODUCT ID: 0x5530

SERIAL: 20040000920A1C707B00

AUTOCONNECT: disabled

IN USE BY: NO ONE

* Group 1 (AW08-D00001.1) (In-use by you)

ADDRESS: AW08-D00001.1

GROUP: 1

NAME: Group 1

PORTS: 1 2 3 4

AUTOCONNECT: enabled

IN USE BY: YOU

+ USB DISK 3.0 (AW08-D00001.1803) (In-use by you)

ADDRESS: AW08-D00010.1803

VENDOR:

VENDOR ID: 0x13fe

PRODUCT: USB DISK 3.0

PRODUCT ID: 0x6300

SERIAL: 070A00376967E000

AUTOCONNECT: inherited

IN USE BY: YOU

* means Autoconnect enabled, + means Autoconnect inherited

Autofind: disabled

Autoconnect All: disabled

AnywhereUSB Manager is running as a service
