Port Clustering
Chapter 10 63
Introduction
Port clustering is the ability to manage many serial ports on one or multiple
slave devices from one master device using a single IP address. For instance,
the Digi CM can manage up to 16 slave devices or a maximum 544 serial ports
with one Master device. Ports can be configured either collectively or
individually depending on user preference. Each master and slave device is
configured separately, they cannot be configured from one master console.
To setup the Digi CM for port clustering you will need to:
• configure all Digi CM serial ports
• assign one Digi CM as the Master clustering device, all other Digi CMs
default to slave devices
• import slave configuration to the Digi CM Master device
Chapter 10
Port Clustering
Slave 2
192.168.1.103
Slave 1
192.168.1.102
IP 211.112.67.34
Master
Ports 7000-7031 - Local
8000-8031 - Slave 1
9000-9031 - Slave 2
Remote PC
Telnet 211.112.67.34 8005
Port 5
Server
