S M - 5 3 0 0 S e r v i c e M a n u a l
S M - 5 3 0 0 S e r v i c e M a n u a l || 6666
Hardware Test And MaintenanceHardware Test And Maintenance
––––––––––––––––––––––––––––––––––––––
7.2 Printer Test
7.2 Printer Test
Procedure PictureProcedure Picture
5) Take a label paper 5) Take a label paper and place in front of the peeland place in front of the peel
sensor, and then check thesensor, and then check the
[Peel Sensor][Peel Sensor]
check boxcheck box
will appear tick mark, that means the peel sensor iswill appear tick mark, that means the peel sensor is
working.working.
6) Remove the cassette and the hole6) Remove the cassette and the hole
[2][2]
is covered,is covered,
then put back the cassette to the scale, and check thethen put back the cassette to the scale, and check the
[Receipt][Receipt]
check box will appear tick mark.check box will appear tick mark.
To Next Page
