Digital Projection E-Vision 7500 Series WIRING DETAILS Connection Guide
24
Rev D July 2014
Wiring Details
Signal inputs and outputs
HDBaseT input
RJ45 socket
3D sync connection
Pin 1 +5V
Pin 2 Ground
Pin 3 Stereo sync
Notes
For full details of all input settings,
see the INPUT menu in the
Operating Guide.
HDBaseT input
VESA 3-pin Mini DIN
