Digital Projection E-Vision 7500 Series PROJECTOR OVERVIEW Installation and Quick-Start Guide
7
Rev D July 2014
Control panel
1
POWER
Off or Standby.
2
INPUT
Select input source.
3
AUTO SYNC
Re-synchronise with the current input signal.
4
ASPECT
Change the aspect ratio.
5
SHUTTER
6
Menu controls
7
Lens controls
Indicators
POWER off = NO POWER
green = normal RUNNING mode red = STANDBY mode
 ashinggreen = PROJECTOR WARM UP
ashingamber = PROJECTOR COOL DOWN
STATUS off = NO ERROR
ashingred(1ash) = COVER OPEN ashingred(4ashes) = FAN ERROR
red = SYSTEM ERROR
LAMPS 1,2 off = OFF
ashingred = LAMP ERROR red = END OF LIFE
ashinggreen = LAMP WARM-UP green = ON
TEMP off = NO ERROR ashing red = ERROR (temperature)
SHUTTER off = OPEN green = CLOSED
ENTER
1
6
2 3 4 5
7
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
POWER STATUS LAMP1 LAMP2 TEMP. SHUTTER
