DISPLAY MESSAGES AND FAULT FINDING
25257 Issue 3 November 2013 4-21
Error signals during the run-up-phase
Possible errors during the run-up-phase are signalled with the signal patterns.
(see table above).
The signal shows the pattern sequentially with 2 characters/second. The
signal is carried out until the control is reset (exception: start of the boot
monitor).
Note: The running light on the 7 segment display (2 linked segments that rotate
clockwise) indicate the boot monitor is active.
Signal 7-Segment Meaning
EE-00001..00FF Error in task initialisation with information about
the task
EE-0100 Error in initialisation of the I2C hardware
EE-0400 Error in initialisation of the serial EEPROM
EE-0800 Error in initialisation of the cyclone FPGA hardware
EE-2000 Error in initialisation of the RTC
