INSTALLATION
25257 Issue 3 November 2013 6-21
The beacon assembly consists of:
• A beacon, which can be mounted up to 3 metres from the printer
• A beacon connector assembly.
The beacon consists of a short tubular aluminium pole carrying four lamps in
“totem pole” style, with a mounting bracket and a 3 metre cable. The beacon
indicators are in a solid state as described below:
Green - printer is printing or ready to print.
Red - there is a fault, printer has stopped.
Amber - printer requires attention.
Blue - printer powered to standby.
Spares and Accessories
For all Spares and Accessory information, please refer to G-Series Spares
Catalogue, part number EPT011376, available via the MyDomino Manuals
Portal.
