Domino G230i User Manual

DESCRIPTION
25257 Issue 3 November 2013 2-11
Print Resolution and Speed
External Connections
Environment
Maximum Horizontal
Resolution (dpi)
Print Speed
(m/min)
Print Speed
(Feet/min)
60 300 984
75 240 787
100 180 590
150 120 394
200 90 295
250 71 230
300 60 197
450 40 131
600 30 98
Product detector (sensor)
connectors:
G130i:/G230i: 15-way D-Type
G220i/G320i: Screw terminal
Shaft encoder connectors: 15-way D-Type socket
Shaft Encoder Input: RS422 Configuration
Inputs: G130i:/G230i: 4 max 24V DC 1A
G220i/G320i: 8 max 24V DC 1A
Outputs: G130i/G230i: 4 max 24V DC 1A
G220i/G320i: 8 max 24V DC 1A
Serial Communications Port
15 way D-Type (G220i/G320i only)
TCP/IP: RJ-45
Data Transfer:
G130i:/G230i: USB memory stick
G220i/G320i: Flash Card
Power connector: 3-way plug, cable supplied
Temperature Range (working) +10º to +40ºC (50ºF to 104ºF)
Temperature Range (Storage) +5º to +40ºC (41ºF to +104ºF)
Humidity 10 - 90% RH (non-condensing)
IP Rating IP54
Electrical Supply 90 - 264Vac 47 - 440Hz (nominal),
Power: 80VA
