Domino G230i User Manual

INSTALLATION
6-6 25257 Issue 3 November 2013
3 Wire PNP Sensor Connection
4 Wire NPN Sensor Connection
Connecting External Dry Contact
Start Print from PLC
Black=Signal1
Input 1-P
Gnd
Blue=0 Volt
Brown=24 Volt
Input 1-N
24 Volt
Input 2-N
24 Volt
Input Block for Input 1 to Input 4
Input 1-N
24 Volt
Input 2-N
24 Volt
Input 1-P
Blue=0 Volt
Brown=24 Volt
Black=Signal1
Input Block for Input 1 to Input 4
Input 1-N
24 Volt
Input 2-N
24 Volt
External Dry Contact
Input Block for Input 1 to Input 4
Input 1-P
Input 1-N
24 Volt
Input 2-N
24 Volt
Input Block for Input 1 to Input 4
Input 1-P
PLC Signal O Volt
PLC Signal +24V when Active
