Domino G230i User Manual

25257 Issue 3 November 2013 7-5
BOARD SPECIFICATION
i-Tech Print Heads
Max No. of Print Heads:
Max No. of Print Groups:
Print Speed:
4
4
From 300mm/min (984 ft/min) at 60 dpi; to,
30m/min (98 ft/min) at 60dpi
Maximum Print Height: 50.8mm / 2” (4 x 12.7mm)
Graphics: Monochrome, bitmaps
Interfaces: Ethernet, RS232, Modbus, Dynamark 3
Barcodes & 2D Codes: EAN 8, EAN 13, UPC-A, UPC-E, Code39,
EAN128, Code128, ITF14, Interleaved 2/5,
Data Matrix (ECC 200), GS1Datamatrix
Barcode Library including an extended
barcode library, e.g, QR-Code, GS1 DataBar,
PPN-Code, PDF417 and many others
Fonts: Arial, Courier; other True Type fonts can be
loaded
Board Dimensions: Width: 226mm
Depth: 115mm
Length: 356mm
Digital Inputs:
Digital Outputs:
Product Speed Detection:
8 (NPN/PNP / 24V-Sensor), configurable
8 (24V), configurable
Configurable Inputs/Outputs: e.g. start print
(D-top), print direction, ready to print, print
busy, alarm, ink cartridge low, cartridge empty
2 x RS424 Shaft Enocoder inputs
G-Series i-Tech Features: Automatic Ink Detection, Ink Level Sensing
on cartridge chip, Cartridge Present
Detection, Ink Cartridge Health Check
feature
Range Specifications
Operating Voltage:
Frequency:
Power:
Operating Temperature:
90 – 264 VAC
47 – 440 Hz
80 VA
0 – 50 °C
