PRINTING MESSAGES
Before a message can be printed it must be loaded in a group and that group
configured to the install configuration.
A group is an assembly of print heads. Depending on the G-Series model, the
printer can have up to 4 groups and one group can combine 1, 2, 3 or 4 print
heads, with a maximum of 4 heads per controller. Refer to “Configuration”
on page 2-8 for a detailed description of available configurations.
When printing, a group is linked to a message (including parameters:
resolution, margin/offset, print area, alignment, print direction and print
speed), to a start signal and to a speed (fixed or measured by a shaft encoder).
Each group is set up during the printer installation.
Once a message is loaded in a group, the group must be activated for printing.
Notes: (1) The confirmation messages displayed when a message is put online to
print, or a message is loaded, can be inhibited from displaying. This
option can be selected through Service>Config>Assign Groups; see
“Assign Groups” on page 3-7.
(2) If you do not inhibit the display of confirmation messages you will need to
deactivate any activated Group to which you wish to load a new message.
Loading and Printing a Message from the
Library
If only one group is installed and the “Start/Stop” button LED is illuminated
green then only that group is activated.
Deactivating the Group
(1) Press the “Start/Stop” button to open the
“Print” screen.
(2) Press the “Print Group 1” button to
confirm deactivation of the print head
group.
Loading the message
(1) In the Message menu select the required message.
(2) Press the “Load Message” button.
(a) If only one group is installed confirm you wish to load and receive
conformation that the message has been loaded.
(b) If more than one group is installed the “group” screen will be
displayed. Press the relevant button to select the group into which
you wish to load the message.
(c) Press the “Select All Groups” button to load the message in all
G130i/G230i G320i
