INSTALLATION
6-20 25257 Issue 3 November 2013
OPTIONAL ALARM BEACON
WARNING: Disconnect beacon from the printer or remove
mains power from the printer before
disassembling the beacon to reposition the
LED colours.
Number Led Colour
1Green
2Red
3Amber
4Blue
Note: The above listing describes the default position of the LED colours as
supplied. The LED colours can be moved into different positions by
removing the centre screw at the top of the beacon. The LED’s are fitted
into three individual keyed sections. Once the screw is removed, the
sections can be reassembled into any user specific order.
1
2
3
Hole Dia 5.5mm
45mm
12.5mm
12.5mm
Mounting Dimensions
SW_0117
GS_0011
4
To Next Page
