Domino G230i User Manual

INSTALLATION
6-4 25257 Issue 3 November 2013
Wiring the G220i / G320i Controller
WARNING: Ensure the mains power is isolated from the
printer when the controller is wired up and
connections are made to the panel.
Mains cable fitted to
the connector on the
power supply
N
E
L
Mains Connector
All Cables to be fed
through Cable Gland
Print head 1
Print head 3
Print head 4
Print head 2
Ethernet
RS232
CAN Bus
Encoder 1
Encoder 2
Output Input
Input
1-8 5-8 1-4
Mains Switch
Connection
Panel
Sensor
Switches
PLC Trigger
Alarm
Beacon
Logic Levels
External
Triggers
Message
Select
