Domino G230i User Manual

DISPLAY MESSAGES AND FAULT FINDING
4-22 25257 Issue 3 November 2013
PRINT QUALITY FAULTS
Problem Example Action
Print face too far
away from the
substrate
Lower the print head
until print quality is
acceptable
Print face
touching the
substrate
Raise the print head
until the print quality is
acceptable
Print face at an
angle
Ensure the rows of
print nozzles are
parallel with the
leading edge of the
substrate
Print nozzles
parallel with
movement of
substrate
Ensure the print
nozzles are
perpendicular to the
product movement
Print face nozzles
have become
blocked
Wipe print face or
perform a micro purge.
If the nozzles do not
unblock replace the ink
cartridge
Print becomes
blurred over the
top or bottom of
the text
Print nozzles are
perpendicular to
product movement,
however the print face
is not parallel to the
substrate
