Domino G230i User Manual

DESCRIPTION
2-10 25257 Issue 3 November 2013
PRINTER SPECIFICATION
Standard Finish: Chassis: Powder Coated Steel
Controller Dimensions:
(G130i/G230i)
Length:250mm (9.8")
Width: 270mm (10.6")
Depth: 100mm (2.9")
Controller Dimensions:
(G220i/G320i)
Length: 340mm (13.4")
Width: 340mm (13.4")
Depth: 139mm (5.5")
Weight: 10kg (22lbs)
GAH 2001 Standard Print
Head Dimensions:
Length: 222mm (8.7")
Width: 95mm (3.7")
Depth: 28.6 (1.1") 66mm (2.6") with base
plate.
GAH2501, GAH2502 (Top
and front connections) Low
Profile Print Head
Dimensions:
Length: 152mm (6.0")
Width: 57mm (2.2")
Depth: 50mm (2.0")
Print Height (Maximum): G130i/G230i: 25.4mm (1") (2x12.7mm)
G220i/G320i: 50.8mm (2") (4x12.7mm)
No. of Print Heads per
Controller
G130: 2
G230i: 2
G220i: 4
G320i: 4
No. of Print Groups G130i: 2
G230i: 2
G220i: 2
G320i: 4
Cable Length: 5, 10 or 25 metres

Domino G230i Specifications

General

Brand	Domino
Model	G230i
Category	Laboratory Equipment
Language	English
