Vigor2925 Series User’s Guide

254

Available settings are explained as follows:

Item Description

Mode

Analyze how a packet will be sent – Choose such mode to

make Vigor router analyze how a single packet will be sent

by a route policy.

Analyze how multiple packets… - Choose such mode to

make Vigor router analyze how multiple packets in a

specified file will be sent by a route policy.

Packet Information

Specify the nature of the packets to be analyzed by Vigor

router.

ICMP/UDP/TCP/ANY- Specify a protocol for diagnosis.

Src IP – Type an IP address as the source IP.

Dst IP – Type an IP address as the destination IP.

Dst Port – Use the drop down list to specify the destination

port.

Analyze – Click it to perform the job of analyzing. The

analyzed result will be shown on the page. If required, click

export analysis to export the result as a file.

Input File

Select – Click the download link to get a blank example

file. Then, click such button to select that blank “.csv” file

for saving the result of analysis.

Analyze – Click it to perform the job of analyzing. The

analyzed result will be shown on the page. If required, click

export analysis to export the result as a file.
