Vigor2925 Series User’s Guide
507
Item Description
SSL Tunnel - It allows the remote dial-in user to make an SSL
VPN Tunnel connection through Internet, suitable for the
application through network accessing (e.g.,
PPTP/L2TP/IPSec)
If you check this box, the function of SSL Tunnel for this
account will be activated immediately.
Specify Remote Node - Check the checkbox to specify the IP
address of the remote dial-in user, ISDN number or peer ID
(used in IKE aggressive mode). If you uncheck the checkbox,
the connection type you select above will apply the
authentication methods and security methods in the general
settings.
Netbios Naming Packet
Pass – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
Block – When there is conflict occurred between the
hosts on both sides of VPN Tunnel in connecting, such
function can block data transmission of Netbios Naming
Packet inside the tunnel.
Multicast via VPN - Some programs might send multicast
packets via VPN connection.
Pass – Click this button to let multicast packets pass
through the router.
Block – This is default setting. Click this button to let
multicast packets be blocked by the router.
Subnet
Chose one of the subnet selections for such VPN profile.
Assign Static IP Address – Please type a static IP address for
the subnet you specified.
User Name
This field is applicable when you select PPTP or L2TP with or
without IPSec policy above.
Password
This field is applicable when you select PPTP or L2TP with or
without IPSec policy above.
Enable Mobile
One-Time Passwords
(mOTP)
Check this box to make the authentication with mOTP
function.
PIN Code – Type the code for authentication (e.g, 1234).
Secret – Use the 32 digit-secret number generated by mOTP in
the mobile phone (e.g., e759bb6f0e94c7ab4fe6).
