Connector Pinouts and LEDs
DS1103 Hardware Installation and Configuration March 2004
177
■■■■■■■■■I
■■■■■■■■■■■■■■
Slave DSP Flash Jumper (J1)
The slave DSP contains an on-chip flash memory. The flash jumper (see
Board Overview on page 161) is used to set the protection mode of
the flash memory and the slave DSP watchdog mode.
The VCCp pin of the TMS320F240 slave DSP selects the protection
mode of the flash memory and the slave DSP watchdog mode:
If the jumper connects VCCp to VCC (default setting):
erase/write operations to the flash memory are enabled
the watchdog is disabled
If the jumper connects VCCp to GND:
erase/write operations to the flash memory are disabled
the watchdog is enabled
N
The dSPACE software does not support the watchdog of the slave DSP.
For this reason, do not change the jumper’s default setting shown
above.
123
GND VCCp VCC
