DS1103 Hardware Installation and Configuration March 2004
33
▲ ■■■■■■■■■■I
▲■■■■■■■■■■■■■■■
Resource Requirements of
dSPACE Boards
Depending on the installation, dSPACE boards require resources in the
host PC and the expansion box.
Installation in the Host PC
The following table lists the required I/O address range together with
the default address and the required memory of dSPACE boards when
installed in the host PC. Some dSPACE boards support plug & play. In
this case, they require an interrupt request line (IRQ). Nevertheless, the
boards operate correctly, even if no free IRQ is available.
T
The resource requirements listed in this table apply to the host PC.
Board
Required I/O
Address Range
Default I/O
Base Address
Required
Memory Range
Required
IRQ
DS1003 8H 318H 64 KB, range
starting at
0xD0000H
None
DS1003/DS1004
(AlphaCombo)
10H 310H 64 KB, range
starting at
0xD0000H
None
DS1005 10H 300H None None
DS1102 10H 300H None None
DS1103 10H Plug & Play None 1 (ISA)
DS1104 – – 2 x 4 KB 1 (PCI)
DS2301 and DS2302 10H 320H None None
DS811
(No DS1003 in the connected
expansion box)
40H 300H None None
DS811
(One or more DS1003 in the
connected expansion box)
40H 300H 64 KB, range
starting at
0xD0000H
None
DS813 10H Plug & Play None 1 (ISA)
DS815 10H Plug & Play None 1 (ISA)
DS817 10H Plug & Play None 1 (PCI)
