Data Sheets
DS1103 Hardware Installation and Configuration March 2004
229
ā²
ā ā ā ā ā ā ā ā ā ā I
ā²ā ā ā ā ā ā ā ā ā ā ā ā ā ā ā
AutoBox with heater The following diagram shows the physical dimensions of the AutoBox
with heater that diverge from the one without heater.
Tandem-AutoBox Dimension Drawings
N
For mounting you should add approx. 0.1 m (3.9 in.) space to the
outer dimensions of the Tandem-AutoBox. This is to allow the
Tandem-AutoBox to vibrate under extreme conditions without
bumping against other devices.
485 mm (19.1 in.)
517.5 mm (20.4 in.)
Not to scale
