DS830 Data Sheet
The following table shows the technical characteristics of the DS830
Multilink Panel.
Parameter Specification
Enclosure Aluminium box (not waterproof)
Connectable boxes Up to 4 (DS830-4), 8 (DS830-8) or 16 (DS830-16)
expansion boxes and/or MicroAutoBoxes
Supported link interfaces DS813, DS814, DS815, DS817, MicroAutoBox
Physical connection In any combination:
• Crossed-over patch cable: twisted pair (CAT5 STP)
• Fiber-optic cable: multimode (50/125 µm)
Cable length per connection • Max. 10 m (crossed-over patch cable)
• Max. 100 m (fiber-optic cable)
Protocol High-speed serial link (proprietary)
Max. transfer rate 100 MBit/s
1)
Status LEDs Various LEDs displaying the current status of each
connection and the power supply
Power supply • +6 V … +58 V DC
• Overvoltage protection and protection against
reverse polarity (± 80 V)
Power consumption DS830-4 16 W
DS830-8 24 W
DS830-16 40 W
Physical size
(length x depth x height)
DS830-4 201.6 x 56.0 x 108.6 mm ( 7.9 x 2.2 x 4.3 in.)
DS830-8 288.0 x 56.0 x 108.6 mm (11.3 x 2.2 x 4.3 in.)
DS830-16 460.8 x 56.0 x 108.6 mm (18.1 x 2.2 x 4.3 in.)
Approx. weight DS830-4 0.75 kg (1.65 lb.)
DS830-8 1.10 kg (2.43 lb.)
DS830-16 1.70 kg (3.75 lb.)
Ambient temperature • 0 … 50 ºC (32 … 122 ºF)
• Active cooling (fan)
1) The transfer rate describes the capabilities of the hardware components and circuits of dSPACE products. Depending on the
software complexity the attainable overall performance can deviate significantly from the hardware specification.
