Mapping of I/O Signals
DS1103 Hardware Installation and Configuration March 2004
207
ā²
ā ā ā ā ā ā ā ā ā ā I
ā²ā ā ā ā ā ā ā ā ā ā ā ā ā ā ā
Conflicts for the Serial Interface
The master PPC of the DS1103 supports only one serial interface. It
can be configured as either RS232 or RS422 transceiver.
Conflicts for the Slave DSP ADC Unit
The following I/O features of the DS1103 conflict with the
Slave DSP ADC unit:
Slave DSP ADC Unit *)
Signal
Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Single Channels
Ch 1 Ch 1 SADCH1 Slave DSP Bit I/O unit Bit 0 Group 1, bit 0
Ch 2 Ch 2 SADCH2 Slave DSP Bit I/O unit Bit 1 Group 1, bit 1
Ch 3 Ch 3 SADCH9 Slave DSP Bit I/O unit Bit 3 Group 1, bit 3
Ch 4 Ch 4 SADCH10 Slave DSP Bit I/O unit Bit 2 Group 1, bit 2
*) Related RTI blocks and RTLib
functions:
ā¢ DS1103SL_DSP_ADC_Cx
ā¢ See Slave DSP ADC Unit in the
DS1103 RTLib Reference
**) Related RTI blocks and RTLib functions:
ā¢ DS1103SL_DSP_BIT_IN_Cx / DS1103SL_DSP_BIT_OUT_Cx
ā¢See Slave DSP Bit I/O Unit in the DS1103 RTLib Reference
