DS1103 Hardware Installation and Configuration March 2004
213
▲ ■■■■■■■■■■I
▲■■■■■■■■■■■■■■■
Conflicts for Slave DSP Square-Wave Signal
Measurement (F2D)
The following I/O features of the DS1103 conflict with Slave DSP
Square-Wave Signal Measurement:
Slave DSP Square-Wave
Signal Measurement (F2D) *)
Signal
Conflicting I/O Feature **)
Ch
(RTI)
Ch
(RTLib)
Ch
(RTI)
Ch
(RTLib)
Conflicts Concerning Slave DSP Square-Wave Signal Measurement as a Whole
• If you perform PWM signal measurement (PWM2D), you cannot measure square-wave signals at the same time.
Conflicts Concerning Single Channels
Ch 1 Ch 1 SCAP1 Slave DSP Bit I/O unit Bit 6 Group 3, bit 4
Ch 2 Ch 2 SCAP2 Slave DSP Bit I/O unit Bit 7 Group 3, bit 5
Ch 3 Ch 3 SCAP3 Slave DSP Bit I/O unit Bit 8 Group 3, bit 6
Ch 4 Ch 4 SCAP4 Slave DSP Bit I/O unit Bit 9 Group 3, bit 7
*) Related RTI blocks and RTLib
functions:
• DS1103SL_DSP_F2D
• See Square Wave Signal
Measurement (F2D) in the
DS1103 RTLib Reference
**) Related RTI blocks and RTLib functions:
PWM2D:
• DS1103SL_DSP_PWM2D
•See Slave DSP PWM Measurement (PWM2D) in the DS1103 RTLib
Reference
Slave DSP Bit I/O Unit:
• DS1103SL_DSP_BIT_IN_Cx/ DS1103SL_DSP_BIT_OUT_Cx
•See Slave DSP Bit I/O Unit in the DS1103 RTLib Reference
