Programming
Operating Instructions 513/533 - 01.0 - 09/2023 33
To change the parameters of a seam pattern (P):
1. Select the seam pattern you wish to change.
2. Press the button.
The menu for changing the parameters is displayed.
Shown on the left side is the parameter to be edited, while
the right side shows the value you entered.
3. To select the desired parameter, press the buttons.
4. To adjust the content, press the buttons.
Setting options
5. To store the input value, press the button.
Explanation Display
Scale X-axis (C001)
You can enter the scaling in % or
as an actual amount (defined by
parameter U063).
Scale Y-axis (C002)
You can enter the scaling in % or
as an actual amount (defined by
parameter U063).
Speed (C004)
The input number is limited by
the maximum speed, which is set
by parameter U001.
Another option is to press the Speed
button in programming mode, which
allows you to enter the value directly.
