Programming
Operating Instructions 513/533 - 01.0 - 09/2023 55
Fig. 42: Setting the parameters (2)
4. Select the desired parameter (1) using the buttons.
5. Use the buttons to set the value (2).
6. To save your setting, press the button.
The settings have been saved, and you have been returned
to the system menu.
7. Press the button again.
The machine is ready to sew again.
4.7 Parameter list
(1) - Parameter (2) - Value
No. Function Value range Unit Default
U001 Maximum speed during sewing 400 to 3200 rpm 3000
U002 Sewing speed of the 1
st
stitch
(with thread-pulling knife)
400 to 1500 rpm 1500
U003 Sewing speed of the 2
nd
stitch
(with thread-pulling knife)
400 to 3200 rpm 2500
U004 Sewing speed of the 3
rd
stitch
(with thread-pulling knife)
400 to 3200 rpm 2700
U005 Sewing speed of the 4
th
stitch
(with thread-pulling knife)
400 to 3200 rpm 3000
U006 Sewing speed of the 5
th
stitch
(with thread-pulling knife)
400 to 3200 rpm 3200
