dynabook PORTEGE X40-J Series - Figure 4-42 Installing the LCD Unit (1)

Maintenance Manual (960-942) 4-37
Replacement Procedures
2. Peel off the separators on the bound & detach tapes on the LCD cover.
Figure 4-42 Installing the LCD unit (1)
3. Set the LCD unit in place.
4. Arrange the LCD harness under the guides of the LCD cover.
When connect the LCD harness, make sure to connect the right and left
side at the same time as shown in the figure below.
