dynabook PORTEGE X40-J Series - Figure 4-44 Installing the LCD Unit (4); Figure 4-45 Installing the LCD Unit (5)

Maintenance Manual (960-942) 4-39
Replacement Procedures
Figure 4-44 Installing the LCD unit (4)
7. Set the LCD mask on the LCD cover while engaging the latches.
Figure 4-45 Installing the LCD unit (5)
8. Engage all the latches following the order in the figure below.
1
2
3
4
4
